Blank Draw Nuts
Machinable Connector for B Series Chucks
Key Features
- Blank connector to be machined to suit specific drawtube threads
- Other lengths of connector are available
- We can supply drawnuts with the correct thread to suit your machine
Description
Used for mounting a B series chuck onto a drawtube, this connector is supplied blank to be machined out to the required thread. **Some machine setups may require the use of extended connectors as well as a drawnut**
Estimated delivery: Next Day (subject to availability)
Dimensions
| # | Part No | Chuck to Suit | Max. Thread Size | Price | ||
|---|---|---|---|---|---|---|
| 1 | DN-B04 | B04 | M28x1.5 | £286.00 | ||
| 1 | DN-B05 | B05 | M34x1.5 | £286.00 | ||
| 1 | DN-B06 | B06 | M42x1.5 | £286.00 | ||
| 1 | DN-B08 | B08 | M55x2.0 | £286.00 | ||
| 1 | DN-B10 | B10 | M75x2.0 | £330.00 | ||
| 1 | DN-B12 | B12 | M88x2.0 | £330.00 | ||
| 1 | DN-B15 | B15/B18 | M130x2.0 | £330.00 | ||
| 1 | DN-B21 | B21 | M155x3.0 | £330.00 | ||
| 1 | DN-B24 | B24 | M175x3.0 | £489.00 |
