Gridded Fixture Plate
50mm Grid Base Plate to suit Horizontal Machining Centre
Key Features
- Allignment Busing and Thread Hole for Quick Accurate Set-ups
- Ground Flat and Parallel
- Threaded Holes for Side-Location
Description
Cast iron fixture plate with mounting holes. Grid pattern with allignment bushes and threaded inserts for ease of set-up. Ground flat parallel and perpendicular for accuracy. Holes of side location to allow precise loading and setting up of the fixture plate. Designed specifically for use on horizontal machining centres.
Estimated delivery: 7-10 Working Days (subject to availability)
Dimensions
| # | Part No | Size (mm) | Height (mm) | Thread | Pitch of Holes (mm) | Drawings | Price | ||
|---|---|---|---|---|---|---|---|---|---|
| 1 | BP05-50400-0400-12 | 400 | 50 | M12 | 50 |
|
£1,883.00 | ||
| 2 | BP05-50500-0500-12 | 500 | 50 | M12 | 50 |
|
£2,563.17 | ||
| 3 | BP05-50630-0630-12 | 630 | 50 | M12 | 50 |
|
£3,776.50 | ||
| 4 | BP05-50800-0800-12 | 800 | 50 | M12 | 50 |
|
£5,762.17 | ||
| 5 | BP05-50400-0400-16 | 400 | 50 | M16 | 50 |
|
£1,914.50 | ||
| 6 | BP05-50500-0500-16 | 500 | 50 | M16 | 50 |
|
£2,612.17 | ||
| 7 | BP05-50630-0630-16 | 630 | 50 | M16 | 50 |
|
£3,852.34 | ||
| 8 | BP05-50800-0800-16 | 800 | 50 | M16 | 50 |
|
£5,891.67 |
