System 5 1030 Machineable Faceplates
Fully Machineable Aluminium Faceplates
Key Features
- Switch between jaws and faceplates in seconds
- Clamp more complex workpieces
- Clamp more components at a time
- Load faceplates outside the machine for better efficiency
Description
Faceplates form the base for a fixture to mount directly to the QwikLOK. They are ideal for complex workpieces that cannot be mounted in soft jaws and also allow smaller workpieces to be clamped in larger quantities. Combine a faceplate with simple workstops and clamps to buld a multi component fixture that can be loaded outside the machine. Add another identical faceplate and you have a manual pallet changing system to virtuallly eliminate loading time.
Estimated delivery: Next Day (subject to availability)
Dimensions
| # | Part No | Width (mm) | Height (mm) | Length (mm) | Price | ||
|---|---|---|---|---|---|---|---|
| 1 | 5FP1030-10-40 | 99 | 40 | 298 | £292.00 | ||
| 1 | 5FP1030-10-55 | 99 | 55 | 298 | £354.00 | ||
| 1 | 5FP1030-15-40 | 148 | 40 | 298 | £421.00 | ||
| 1 | 5FP1030-15-55 | 148 | 55 | 298 | £501.00 |
